The TRENDnet AX3000 Wireless Dual Band & Bluetooth 5.2 PCIe Adapter simultaneously provides Bluetooth and Wi-Fi connections, allowing you to concurrently connect to a Wi-Fi network and Bluetooth devices. You can conveniently download music, videos, and pictures from a wireless internet connection, and then transfer those same files seamlessly to your Bluetooth-enabled phone or device.

Features

• Dual Bluetooth and Wi-Fi Connectivity

  Simultaneously provides Bluetooth and Wi-Fi connections, allowing you to concurrently connect to a Wi-Fi network and Bluetooth devices.


• Fast Wi-Fi Speed

  The adapter supports the latest Wi-Fi 6 (802.11ax) standard, providing faster wireless speeds and improved efficiency compared to previous Wi-Fi standards.

• Transfer to Bluetooth-enabled devices

  You can conveniently download music, videos, and pictures from a wireless internet connection, and then transfer those same files seamlessly to your Bluetooth-enabled phone or device.


• WPA3 Encryption

  Wi-Fi security standard, WPA3, providing enhanced protection for your wireless network.

• Beamforming Technology

  Beamforming technology helps to improve Wi-Fi signal strength and coverage by focusing the signal toward connected devices rather than broadcasting it in all directions.

• Easy Installation

  PCIe adapters are generally easy to install in desktop computers with an available PCIe slot.

COMPATIBILITY

Protocol

Works with

Only compatible on a computer with a PCIe 2.0 x1 interface and only supports the following operating systems. Windows 10 (32/64-bit), Windows 8 (32/64-bit), 7 (32/64-bit), Vista (32/64-bit), Windows XP (32/64-bit).

SPECS

Technical Specifications

• Encryption: Wireless encryption- WEP, WPA/WPA2-PSK, WPA/WPA2-Radius, WPA3
• Frequency: 2.4GHz: 2.412 – 2.462GHz, 5GHz: 5.150 – 5250 GHz
• Modulation: DBPSK/DQPSK/CCK for DSSS technique, BPSK/QPSK/16-QAM/64-QAM/256-QAM/1024-QAM for OFDM technique, OFDMA
• Antenna Gain:2.4GHz: 2 x 3.24 dBi (max.), 5GHz: 2 x 4.97dBi (max.)
• Wireless Output Power: 802.11a: 16 dBm (max), 802.11b: 16.5 dBm (max), 802.11g: 16.5 dBm (max),802.11n: 18 dBm (max), 802.11ac: 14 dBm (max), 802.11ax: 14.75 dBm (max)
• Receiving Sensitivity: 802.11a: -77 dBm (typical) @ 54Mbps, 802.11b: -89 dBm (typical) @ 11Mbps, 802.11g: -76 dBm (typical) @ 54Mbps,802.11n: -73 dBm (typical) @ 600Mbps, 802.11ac: -61 dBm (typical) @ 1733Mbps, 802.11ax: -63 dBm (typical) @ 2401Mbps
• Wireless Channels: 2.4GHz: FCC: 1 – 11, 5GHz: FCC: 36, 40, 44, 48, 149, 157, 161, 165;
• Compatibility: Windows: 10 (64-bit) and 11 only
• Power: Max. consumption: 6.1W
• Operating Temperature: 0° – 40° C (32° – 103° F)
• Operating Humidity: Max. 90% non-condensing
• Dimensions: 87 x 55 x 17mm (3.43 x 2.17 x 0.7 in.)

INSTALLATION

Installation Guide

Manual
