The Insteon Plug-in Siren is an essential add-on to instantly create a custom alert system - just plug into a wall outlet and pair with Insteon Sensors! The Insteon Plug-in Siren can be set to "Siren" mode that generates a loud 115db alarm when triggered by sensors, or a "Chime" mode that generates a pleasant chime to let you know when something happens at home. Keep your home and loved ones safe and secure by adding a Insteon Plug-in Siren to your Insteon system.

Features

• Turn your smart home into your own Insteon Alert System


  Add the Insteon Plug-in Siren to turn your smart home into your own Insteon Alert System - just plug into a wall outlet and pair with Insteon Sensors!


• Customize your alert system


  The Insteon Plug-in Siren can be paired with different sensors to create your own customized alert system, such as a water sensor to be alerted in case of water leaks, or door/window sensors to create a security perimeter around your home.

• Siren or Chime Mode


  The Insteon Plug-in Siren can be set to "Siren" mode that generates a loud 115db alarm when triggered by sensors, or a "Chime" mode that generates a pleasant chime to let you know when something happens at home.


• Easy to Setup


  The Insteon Plug-in Siren is easy to setup - just plug directly into a wall outlet without worrying about wires to deal with or holes drilled into walls.


• Dual Band Technology


  The Insteon Plug-in Siren uses Insteon dual mesh radio and powerline communication for wireless convenience and best possible communication reliability.

SPECS

Technical Specifications

• Manufacturer: Insteon
• Manufacturer Product No.: 2868-222 - (Each)
• Patent No.: U.S. Patent No. 7,345,998. Protected under U.S. and foreign patents

• FCC ID: SBP2457D2A

• Industry Canada: 5202A-2457D2A

• Warranty: 2 Years

• Audio Alert: Beeper, Chime, Siren

• Chime Volume: 100 dB at 1 meter

• Siren Volume: 115 dB at 1 meter

• Setup Memory: Non-volatile EEPROM

• Status LED: Red/Green LED

• Insteon Device Category: 0x07

• Insteon Device Subcategory: 0x1E

• Insteon Links: 24

• Insteon Messages Repeated: Yes

• Insteon Minimum Receive Level: 10 mV

• Insteon Minimum Transmit Level: 3.2 Vpp into 5 Ohms

• Insteon Powerline Device: Yes

• Insteon Powerline Frequency: 131.65 KHz

• Insteon RF Device: Yes

• Multi-Link Support: Yes

• Multi-Unlink Support: Yes

• RF Beacon: Yes

• Radio Frequency: 915.0 MHz

• Radio Frequency Range: 150 ft. (Depending on your home’s construction)

• Scene Commands Supported as Controller:
• Fast-On
• Fast-Off
• Scene Commands Supported as Responder:
• On, Fast-On
• Off
• Software Configurable: Yes

• Dimensions:
• 3.2” H x 2.05” W x 1.05” D
• 81.2mm H x 53mm W x 26.6mm D<
• Enclosure Material: UV stabilized plastic

• Mounting: Ungrounded, polarized electrical outlet, NEMA 1-15

• Operating Environment: Indoors

• Operating Humidity Range: 0-85% relative humidity, non-condensing

• Operating Temperature Range:
• 32º to 104º F
• 0º to 40º C
• Set Button: Yes

• Storage Temperature Range:
• -4º to 158º F
• -20º to 70º C
• Weight: 3.3 oz
• Power Consumption: <0.75 Watts

• Supply Voltage: 120 Volts AC ± 10%, 60 Hertz, single phase

• Surge Resistance: Surges over 1,000 volts
• Includes:
• 1x - Insteon Siren
• 1x - Quick Start Guide
